Coiled Tubing & Control Line
Precision coiled tubing and control line tube in duplex and nickel alloys for downhole, subsea, and oilfield service applications.
Overview
TOKO TECH manufactures high-precision coiled tubing and control line tube in duplex stainless steel and nickel alloys. Our products are engineered for the demanding environments of downhole well intervention, subsea hydraulic control systems, chemical injection lines, and instrumentation tubing. Tight dimensional tolerances and superior surface finish ensure reliable performance in critical oilfield applications.
Key Features & Quality Control
Specifications
| Process | Material | OD Range | WT Range | Standard | Length |
|---|---|---|---|---|---|
| Seamless | 304 / 304L | 1/8" – 1" (3.18 – 25.4mm) | 0.028" – 0.120" (0.71 – 3.05mm) | ASTM A269 / A213 | Coil (up to 3,000m) |
| Seamless | 316 / 316L | 1/8" – 1" (3.18 – 25.4mm) | 0.028" – 0.120" (0.71 – 3.05mm) | ASTM A269 / A213 | Coil (up to 3,000m) |
| Seamless | Duplex 2205 | 1/4" – 1" (6.35 – 25.4mm) | 0.035" – 0.120" (0.89 – 3.05mm) | ASTM A789 / A790 | Coil (up to 2,500m) |
| Welded | 304 / 304L | 1/4" – 1" (6.35 – 25.4mm) | 0.028" – 0.083" (0.71 – 2.11mm) | ASTM A269 / A249 | Coil (up to 3,000m) |
| Welded | 316 / 316L | 1/4" – 1" (6.35 – 25.4mm) | 0.028" – 0.083" (0.71 – 2.11mm) | ASTM A269 / A249 | Coil (up to 3,000m) |
| Welded | Duplex 2205 | 1/4" – 1" (6.35 – 25.4mm) | 0.035" – 0.083" (0.89 – 2.11mm) | ASTM A789 / A790 | Coil (up to 2,500m) |
Typical Applications
Downhole Control Lines
Hydraulic control lines for sub-surface safety valves, flow control devices, and intelligent well completions. Rated for high-pressure, high-temperature (HPHT) well conditions.
Subsea Umbilicals
Core component of subsea umbilical systems providing hydraulic, chemical injection, and electrical signal pathways between surface facilities and subsea equipment.
Chemical Injection Lines
Precision lines for injecting corrosion inhibitors, scale inhibitors, methanol, and other chemicals directly into wellbores and flowlines to maintain flow assurance.
Instrumentation & Sensing
Small-diameter tubing for pressure gauges, temperature sensors, fiber optic monitoring, and distributed sensing systems in permanent downhole monitoring.
Applicable Standards
Explore Materials Used in This Product
Review detailed material data, chemical composition, and mechanical properties for every grade we offer:
Need a Quote for Coiled Tubing & Control Line?
Send us your specifications — material grade, OD, wall thickness, and length — and we'll get back within 24 hours.
