Stainless Steel Butt Weld Elbows (45° & 90°)
ASME B16.9 long-radius and short-radius elbows in 304/316L/Duplex, 1/2"-48". Full material traceability with PMI verification.
Types
45° and 90°; Long Radius (LR) and Short Radius (SR)
Size Range
1/2" – 48" (DN15 – DN1200)
Wall Schedule
SCH 5S – XXS
Material
304/304L / 316/316L / Duplex 2205 / Nickel Alloys
Overview
TOKO TECH supplies butt weld elbows in long-radius (LR, R=1.5D) and short-radius (SR, R=1.0D) configurations to ASME B16.9. Our elbows are manufactured from seamless or welded pipe in a comprehensive range of materials and sizes. Every fitting undergoes dimensional inspection, PMI alloy verification, and visual examination per ASME B16.25.
Specifications
| Specification | Value |
|---|---|
| Types | 45° and 90°; Long Radius (LR) and Short Radius (SR) |
| Size Range | 1/2" – 48" (DN15 – DN1200) |
| Wall Schedule | SCH 5S – XXS |
| Material | 304/304L / 316/316L / Duplex 2205 / Nickel Alloys |
| Standard | ASME B16.9 / B16.28 |
Typical Applications
Pipeline 45°/90° directional changesProcess piping headersTransfer line routing
Material Specifications
View detailed chemical composition, mechanical properties, and corrosion resistance data:
Need a Quote for Stainless Steel Butt Weld Elbows (45° & 90°)?
Send us your specifications and we will get back within 24 hours with pricing and availability.
