Stainless Steel Butt Weld Reducers (Concentric & Eccentric)
ASME B16.9 concentric and eccentric reducers for smooth diameter transitions. Min turbulence, max flow efficiency in 304/316L/Duplex.
Types
Concentric and Eccentric
Size Range
3/4"×1/2" up to 48"×40" (DN20 – DN1200)
Wall Schedule
SCH 5S – XXS
Material
304/304L / 316/316L / Duplex 2205
Overview
TOKO TECH butt weld reducers enable smooth transitions between different pipe diameters. Concentric reducers maintain centerline alignment (ideal for vertical piping). Eccentric reducers keep one side flat (preferred for horizontal runs to prevent air pockets). Available in all standard materials and schedules.
Specifications
| Specification | Value |
|---|---|
| Types | Concentric and Eccentric |
| Size Range | 3/4"×1/2" up to 48"×40" (DN20 – DN1200) |
| Wall Schedule | SCH 5S – XXS |
| Material | 304/304L / 316/316L / Duplex 2205 |
| Standard | ASME B16.9 |
Typical Applications
Diameter transitions in process linesPump suction/discharge connectionsFlow meter installations
Material Specifications
View detailed chemical composition, mechanical properties, and corrosion resistance data:
Need a Quote for Stainless Steel Butt Weld Reducers (Concentric & Eccentric)?
Send us your specifications and we will get back within 24 hours with pricing and availability.
